Vertiv Liebert GXT5 external battery cabinet for 5kVA-10kVA – GXT5-EBC192VRT3U





GXT5-EBC192VRT3U, Liebert® External Battery for 192V Liebert® GXT5 UPS

The Vertiv™ Liebert® GXT5-EBC192VRT3U is an external hot-swappable, lead-acid UPS battery cabinet designed for use with these UPS models: Liebert® GXT5-5000HVRT5UXLN, Liebert® GXT5-6KL630RT5UXLN, Liebert® GXT5-8000HVRT5UXLN, and Liebert® GXT5-10KHVRT5UXLN. Its new auto detection feature makes installation easy and fast ensuring the UPS configuration is complete and accurate. Users can connect to up to 10 external battery cabinets to a single UPS for extended runtime.





Overview



The full range of single-phase Vertiv™ Liebert® GXT5 UPS systems are easy to deploy with convertible rack/tower design that offers installation flexibility. Its gravity-sensing, color LCD provides a user-friendly interface for local configuration and management. Setup and integration are also easy with auto-detection of matching external battery cabinets for additional runtime solutions. With available network interface card (NIC), the Vertiv suite of management solutions including Trellis™ Power Insight and Vertiv™ LIFE™ Services are available to support your critical infrastructure. Designed for high availability and capacity, these compact UPS models with output power factors up to unity provide more usable power for connected equipment. High efficiency operation of this Energy Star 2.0 certified UPS means you get protection while supporting sustainability. Increased efficiency is also achieved with Active ECO operating mode.

Key Benefits



Features

Benefits

• More usable power to support more connected loads for cost and space savings
• Simplified installation and operation
• Remote UPS firmware upgrade capability
• Ability to prioritize critical loads
• Improved ability to manage connected devices without impacting continuity
• Streamlined remote monitoring and operational efficiency
• Faster deployment and accurate runtime information
• Intelligent battery health management for optimized service life
• Optimized energy and capacity management





Short Tech Specification



Vertiv Liebert GXT5 external battery cabinet for 5kVA – 10kVA product variants





Detailed Tech Specification



GXT5-EBC192VRT3U



USED WITH UPS MODEL

• 5 – 10 KVA MODELS



Dimensions (D×W×H)

Unit

• 630 x 430 x 130



Weight (kg)

Unit

• 57.6



Battery

Type

• Valve-regulated, non-spillable, lead acid

Qty×V

• 16 × 12V



Environmental Requirements

Operating Temperature,°F (°C)

• 0 to 40 (32 to 104)

Storage Temperature, °F(°C)

• -15 to 40 (5 to 104)

Relative Humidity

• 0 – 95%, non-condensing

Operating Elevation

• Up to 9,842.5 ft. (3000m) at 77ºF (25ºC)



Agency

Safety

• IEC62040-1:2008 version, GS mark; UL1778, c-UL listed

Transportation

• ISTA Procedure 1E
