Vertiv Liebert GXT5 / Vertiv Edge UPS External Battery cabinet for 1.5kVA-2kVA (GXT5) and 1.5kVA (Edge) – GXT5-EBC48VRT2UE





GXT5-EBC48VRT2UE, Vertiv Liebert External Battery 48V for Liebert GXT5 UPS (1500VA-2kVA)

 The Vertiv Liebert GXT5-EBC48VRT2UE is a hot-swappable, lead-acid UPS battery cabinet designed for use with Liebert GXT5-1500IRT2UXLE and Liebert GXT5-2000IRT2UXLE UPS systems. Its new auto detection feature makes installation easy and fast ensuring the UPS configuration is complete and accurate for the solution installed. Power and communications ports allow up to 6 additional external battery cabinet units to power the UPS for extended runtime.





Overview



The Vertiv™ Liebert® GXT5 UPS offers a full range of single-phase UPS. It’s easy to deploy with convertible rack/tower design that offers installation flexibility, and its gravity-sensing, color LCD provides a user-friendly interface for local configuration and management. Setup and configuration is also made easy auto-detection of external battery cabinets for additional runtime solutions. With available network card (NIC), the Vertiv suite of management solutions including Trellis™ Power Insight and Vertiv™ LIFE™ Services remote service delivery tools are available to support your critical infrastructure. Designed for high availability and capacity, these UPS models with high output power factors up to unity, provide more usable power in a compact solution, enabling more usable power for connected equipment. High efficiency operation of this Energy Star 2.0 certified UPS means you get protection while being energy conscience. Increased efficiency is also achieved with Active ECO operating mode.

Key Benefits



Features





Short Tech Specification



Vertiv Liebert GXT5 / Vertiv Edge external battery cabinet for 1.5kVA – 2kVA (GXT5) and 1.5kVA (Edge)





Detailed Tech Specification



GXT5-EBC48VRT2UE



Rating

Power Rating

• 1500 – 2000 VA



Dimensions (D×W×H)

Unit

• 497 x 430 x 85



Weight (kg)

Unit

• 28.8



Battery

Type

• Valve-regulated, non-spillable, lead acid

Qty×V×Rating

• 2×4 × 12V × 9.0Ah



Environmental Requirements

Operating Temperature,°F (°C)

• 32 to 104 (0 to 40)

Storage Temperature, °F(°C)

• 5 to 104 (-15 to 40) High ambient temperatures will reduce battery life

Relative Humidity

• 0% to 95%, non-condensing

Operating Elevation

• Up to 10,000 ft. (3000m) at 77ºF (25ºC) without derating



Agency

Safety

• EN 62040-1:2008+A1:2013;
  GS mark;
  UL 1778 5th Edition and CSA 22.2 No. 107.1

EMC

• EN 62040-2:2006
  EN 61000-3-2:2014
  EN 61000-3-3:2013

Transportation

• ISTA Procedure 1A

Surge Immunity

• ANSI C62.41 Category B

RFI/EMI

• FCC Part 15 (Class A)
