APC Galaxy VS UPS 20kW 480V, 1 internal 7Ah smart modular battery string, expandable to 2, Start-up 5×8 – GVSUPS20KB2GS
Brand: APC
AED 63,470.00 excl. VAT
APC Galaxy VS UPS 20kW 480V
- Up to 99% efficient in eConversion mode
- Maximize availability with modular architecture
- Live Swap: Third party verified module replacement with no scheduled downtime
- Unlock resiliency and sustainability with access to EcoStruxure software
- 1-year Secure NMC Subscription, allowing the customer to access future firmware updates, is included with purchase
- Part No : GVSUPS20KB2GS
[ratingwidget type="page"]
AED 63,470.00 excl. VAT
Best Price: AED 61,883.25 on Bank Transfer / Cash Payment (-AED 1,586.75)
Estimated delivery between Apr 11, 2026 - Jun 22, 2026
For urgent delivery, please contact sales before ordering. Orders usually ship as per the estimated delivery date in certain case backorders may take 4–12 weeks. Images are for illustration only and may differ from the actual item.
APC Galaxy VS UPS 20kW 480V, 1 internal 7Ah smart modular battery string, expandable to 2, Start-up 5×8 – GVSUPS20KB2GS
Overview
Highly efficient, easy-to-deploy 20 kW, 480 V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5×8 start-up service and 1 smart modular battery string, expandable to 2 strings for extended runtime. See the battery runtime chart for details.
- Up to 99% efficient in eConversion mode
- Maximize availability with modular architecture
- Live Swap: Third party verified module replacement with no scheduled downtime
- Unlock resiliency and sustainability with access to EcoStruxure software
- 1-year Secure NMC Subscription, allowing the customer to access future firmware updates, is included with purchase
Published on lastbestprice.com
Specifications
Overview |
|
| Presentation | Highly efficient, easy-to-deploy 20kW, 480V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5×8 start-up service and 1 smart modular battery string, expandable to 2 strings for extended runtime. Runtime charts available in the Documents tab. (600V options available for Canada / Options disponibles pour le Canada) |
Main |
|
| Main Input Voltage | 480 V 3 phase |
| Main Output Voltage | 480 V 3 phase |
| Kw Rating | 20 kW |
| rated power in VA | 20 kVA |
| Output connector type | Hard Wire 4-wire (3PH + G) 1 |
| Hard Wire 5-wire (3PH + N + G) 1 | |
| Battery Type | Internal modular battery |
| VRLA | |
| Provided equipment | Dust filter |
| Installation guide | |
| Integrated network management | |
| Power modules ship installed | |
| Start-Up Service | |
| Top and bottom cable entry | |
| Range of Product | Galaxy VS |
| Range Compatibility | Galaxy VS |
Batteries & Runtime |
|
| Efficiency | View Efficiency Graph |
| Battery Voltage | 480V |
| End of Discharge Battery Voltage | 384 V DC |
| End of Discharge Maximum Battery Current | 54 A |
| Battery power in VAH | 0 VAh runtime |
| Extendable Run Time | 0 |
General |
|
| Bypass Voltage Tolerance | +/- 10 % |
| Redundant | No |
| Product or Component Type | Uninterruptible power supply (UPS) |
Physical |
|
| color | White |
| Height | 58.46 in (148.5 cm) |
| Width | 13.11 in (33.3 cm) |
| Depth | 33.35 in (84.7 cm) |
| Net Weight | 540.1 lb(US) (245 kg) |
| USB compatible | No |
Input |
|
| Input Frequency | 40 – 70 Hz |
| Number of input connectors | 1 Hard Wire 4-wire (3PH + G) |
| Efficiency at full load | 408…552 V 480 V |
| Maximum Input Current per Phase | 30 A |
| Maximum Short Circuit Withstand (Icw) | 65 kA |
| Input Total Harmonic Distortion | Less than 3% for full load |
| Load power factor | From 0.7 leading to 0.5 lagging without any derating |
| Input Power Factor at Full Load | 0.99 |
Output |
|
| Max Configurable Power (Watts) | 20 kW |
| Harmonic distortion | Less than 3% |
| Output frequency | 50 Hz sync to mains |
| 60 Hz sync to mains | |
| 50 Hz +/- 0.1 % for 50 Hz nominal not synced | |
| 60 Hz +/- 0.1 % for 60 Hz nominal not synced | |
| Crest factor | 2.5 |
| Waveform Type | Sine wave |
| Output voltage tolerance | +/-1% after 50ms |
| Output Voltage THD | < 1% linear load and < 3% non-linear load |
| Overload Operation | 10 minutes @ 125% and 60 seconds @ 150% |
| Bypass type | Built-in Static Bypass |
| Maximum configurable power in VA | 20 kVA |
Conformance |
|
| Product Certifications | ENERGY STAR V2.0 (USA) |
| UL 1778 5th edition | |
| Standards | CSA C22.2 No 107.3 |
| FCC Part 15 class A | |
| IEC 62040-3 | |
| IEC 60721-4-2 Level 2M2 | |
| UL 1778 5th edition | |
Environmental |
|
| Ambient air temperature for operation | 32…104 °F (0…40 °C) |
| Relative Humidity | 0…95 % non-condensing |
| Operating altitude | 0…3281 ft |
| Ambient Air Temperature for Storage | 5…104 °F (-15…40 °C) |
| Storage Relative Humidity | 10…80 % non-condensing |
| Storage altitude | 0…10000 ft (0…3048 m) |
| Acoustic level | 65 dBA |
| Heat dissipation | 2225 Btu/h |
| IP degree of protection | IP20 |
Communications & Management |
|
| Free slots | 1 |
| control panel | Touch Screen LCD User Interface |
Ordering and shipping details |
|
| GTIN | 7.31305E+11 |
Packing Units |
|
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 66.14 in (168 cm) |
| Package 1 Width | 38.98 in (99 cm) |
| Package 1 Length | 25.20 in (64 cm) |
| Package weight(Lbs) | 595.2 lb(US) (270 kg) |
Contractual warranty |
|
| Warranty | 1 year on-site repair or replace with factory authorized Start-Up |
