APC NetShelter CX 18U Secure Soundproofed Server Room in a Box Enclosure International – AR4018IA

Overview

AR4018IA Features

NetShelter CX 18U Secure Soundproof Server Room in a Box Enclosure International

• Acoustic foam lining for noise dampening
  Superior noise reduction of installed IT equipment allowing the enclosure to be placed in a quiet environment.
• Adjustable equipment mounting rails
  The equipment mounting rails, front and rear, are fully adjustable for various mounting depths, for rear-facing equipment mounting or additional clearance from the front door. Maximum rack depth 88 cm/34.6 in. Minimum rack depth 12 cm/4.7 in.
• Dedicated rear cable access point
  The cable port has a capacity of up to 400 cables and is situated perfectly for ground or under-floor cabling.
• Integrated heat removal
  High efficiency fan modules remove heat and eliminate the need to purchase a costly cooling unit for your IT equipment.
• Integrated power distribution
  Provided with a rack power distribution unit servers and other equipment are ready for deployment.
• Light oak veneer finish
  The enclosure blends discretely into almost any office environment.
• Removable side panels
  Provides customers with easy accessibility to equipment.
• Six vertical 0U accessory channels
  Provides multiple mounting locations for cable management accessories and rack PDUs without using critical equipment space.

NetShelter CX Features & Benefits

Detailed Tech Specification

Output

• Nominal Output Voltage

  200V , 240V

• Overload Protection

  Yes

• Maximum Total Current Draw

  10

• Output Connections
  (14) IEC 320 C13 (Battery Backup)

Input

• Nominal Input Voltage

  200V , 208V , 230V , 240V

• Input frequency

  50/60 Hz

• Input Connections

  IEC-320 C14

• Input Power

  39.0Watts

Physical

• Maximum Height

  1015mm , 101.5CM

• Maximum Width

  750mm , 75.0CM

• Maximum Depth

  1130mm , 113.0CM

• Rack Height

  18U

• Net Weight

  131.0KG

• Shipping weight

  157.5KG

• Shipping Height

  1250mm , 125.0CM

• Shipping Width

  800mm , 80.0CM

• Shipping Depth

  1200mm , 120.0CM

• Color

  Grey , Oak

• Maximum Mounting Depth

  880.0mm , 88.01CM

• Minimum Mounting Depth

  28.35inches

• Units per Pallet

  1.0

• Rack Width

  19″

Conformance

• Approvals

  EIA 19 Inch, TAA compliance

• Standard warranty

  2 year (manufacturer’s defect)

Sustainable Offer Status

• RoHS

  Compliant

• REACH

  REACH: Contains No SVHCs
