APC Smart-UPS Ultra On-Line, 3000VA, Lithium-ion, Rack/Tower 1U, 230V, 3x C13, 2x C19 IEC outlets, SmartConnect, Extended runtime, W/rail kit – SRTL3KRM1UIC



---



Overview



This APC Smart-UPS SRTL3KRM1UIC is designed for IT professionals or network administrators to maintain business uptime and continuity. This 3kVA on-line 1U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRTL comes with IEC Inlet, 3x IEC C13 and 2x IEC C19 outlets. This Smart-UPS offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 5-year warranty on the UPS and Lithium-ion battery. The SRTL delivers clean power with zero transfer time for critical or sensitive devices. Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications.

• Replacement battery (1) is available
• 3kVA/3KW on-line pure sine wave 1U rackmount UPS
• Add up to 5 external battery packs (SRTL50RMBP1U-Li) for extended runtime
• Graceful shutdown of physical servers, virtual machines and HCI Clusters
• Cloud-based remote power monitoring via SmartConnect Ethernet Port
• Graceful shutdown of physical servers, virtual machines and HCI Clusters



















Published on lastbestprice.com

---



Detailed Tech Specification



Overview

Presentation

• Ultra high density on-line power protection with scalable runtime supported by Lithium-Ion batteries.

Lead time

• Usually in Stock



Main

Run time for load 3000 W

Min-max: 300-3000 W

• 4min 37s

Max. Capacity Used

• 100 %

Main Input Voltage

• 230 V

Product or component type

• Uninterruptible power supply (UPS)

Other Input Voltage

• 230 V

Main Output Voltage

• 230 V

Other Output Voltage

• 230 V

Rated power in W

• 3000 W

Rated power in VA

• 3000 VA

Input Connection Type

• BS1363A British
• IEC 60320 C20
• Schuko CEE 7 / EU1-16P

output connection type

• 3 IEC 60320 C13
• 2 IEC 60320 C19

Number of rack unit

• 1U

Cable length

• 2.4 m

Number of cables

• 1

Battery type

• Li-Ion (Lithium-Ion)

Provided equipment

• RJ45 cable
• USB cable
• Safety guide
• Rack mounting brackets
• Rack mounting support rails
• Wall mounting brackets
• Stabilization feet
• Screws

Range of product

• Smart-UPS Ultra



Complementary

Software package

• SmartConnect software for remote power monitoring feature availability varies by terms of use



Batteries & Runtime

Run Time

• View Runtime Graph

Efficiency

• View Efficiency Graph

Battery recharge time

• 1.5 h

Number of battery replacement quantity

• 1

Battery voltage

• 50 V

Battery charger power

• 448 W

Battery design life

• 8…10 year(s)

Battery life

• 8…10 year(s)

Replacement battery

• APCRBC173-LI

Extended runtime

• 1



General

product web sub-family

• High density

Redundant

• No



Physical

Colour

• Silver grey

Height

• 43 mm

Width

• 432 mm

Depth

• 560 mm

Net weight

• 15.9 kg

Mounting preference

• No preference

Mounting mode

• Rack-mounted with kit
• Tower-mounted with kit

Two post mountable

• 1

USB compatible

• Yes

Mounting position

• Horizontal
• Vertical



Input

Network frequency

• 50/60 Hz auto-sensing

Input voltage limits

• 160…275 V adjustable (half load)



Output

Maximum configurable power in W

• 3000 W

Output frequency

• 50/60 Hz +/- 3 Hz sync to mains

Crest factor

• 3 : 1

UPS type

• On-Line

Wave type

• Sine wave

Output harmonic distortion

• < 2% at 100% linear load and < 5% at 100% non-linear load

Bypass type

• Internal bypass (automatic and manual)

Efficiency

• 98 %

Maximum configurable power in VA

• 3000 VA



Conformance

Product certifications

• CE
• UKCA
• UK PSTI

Marking

• CE Mark
• UKCA

Standards

• EN/IEC 62040-1
• EN/IEC 61000-4-8
• EN/IEC 61000-4-6 level 3
• EN/IEC 61000-4-2 level 3
• EN/IEC 61000-4-3 level 3



Environmental

Ambient air temperature for operation

• 0…40 °C

Relative humidity

• 0…95 % non-condensing

Operating altitude

• 0…10000 ft

Ambient air temperature for storage

• -15…45 °C

Storage Relative Humidity

• 0…95 % non-condensing

Storage altitude

• 0.0000000000…15240.0000000000 m

Acoustic level

• 55 dB

Heat dissipation

• 325 Btu/h

IP degree of protection

• IP20



Communications & Management

control panel

• Touch screen LCD user interface

Alarm

• Audible and visible alarms : prioritized by severity

Emergency power off

• Yes

Communication port support

• SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use
• RJ45: port monitoring
• USB: port monitoring



Surge Protection and Filtering

Surge energy rate

• 1600 J



Packing Units

Unit Type of Package 1

• PCE

Number of Units in Package 1

• 1

Package 1 Height

• 27.8 cm

Package 1 Width

• 56.4 cm

Package 1 Length

• 76.4 cm

Package 1 Weight

• 24.2 kg



Contractual warranty

Warranty

• 5 years repair or replace
