HPE MSA 2070 SFF, 2×10/25GbE iSCSI 4‑port Cntrl, 12×1.92TB SSD 4x10Gb iSCSI XCVR 23TB, 3Yr – P76571-B25



HPE MSA 2070 SFF

Start with the unique and intuitive graphical user interface of HPE MSA Storage Management Utility (SMU) that provides step-by-step instructions and guided workflows to set up the array within minutes.

---



Overview



Features



Simple – The Shared Storage System Anyone Can Use

• Start with the unique and intuitive graphical user interface of HPE MSA Storage Management Utility (SMU) that provides step-by-step instructions and guided workflows to set up the array within minutes.
• System monitoring and maintenance available through a simplified dashboard offers “at-a-glance” views of system alerts, performance, and capacity usage. New HPE MSA Gen7 innovations include support for online controller/media firmware updates as well as simpler and faster access to MSA Health Check.
• System architecture supporting hot-swap controllers, drives, and power supplies, enabling users to quickly complete upgrades and maintenance with minimal downtime.



Fast – Real Performance You Can See and Feel

• Next generation system architecture supporting incredibly fast performance for an entry-level storage solution.  HPE MSA Gen7 delivers up to 2X more IOPS (random) performance with up to 30% more system bandwidth (sequential) as compared to HPE MSA Gen6 Storage.¹
• Real-time, automated data tiering for hybrid configurations, optimizing the use of high-performance SSD media as well as lower-cost HDD storage within the same array. With minimal investment in SSDs, users can increase system IOPS by up to 4X versus HDD-only configurations.³
• HPE MSA-DP+ advanced RAID technology eliminates the use of idle spare drives by distributing spare capacity across all drives in the disk group and enabling drive rebuild times that are up to 25X faster than traditional RAID.⁴



Affordable – Great Value Across All MSA Configurations

• Start small and scale as needed with any combination of SSDs, Enterprise SAS or Midline SAS HDDs. “Grow as you go” upgrades are available through low-cost HPE MSA SSD and HDD media 6-packs.
• Wide range of HPE MSA Gen7 Storage Array models including value-driven solution bundles for hybrid-flash and all-flash configurations providing a cost-effective path to high-performance storage on Day 1.
• Minimize resources dedicated to daily maintenance and focus on business outcomes with HPE MSA Health Check. A cloud-based tool available to all MSA users at no additional charge, Health Check uses MSA system logs to assess performance and configurations against HPE MSA best practice guidelines.



Published on lastbestprice.com

---



Short Tech Specification

HPE MSA 2070 SFF 2×10/25GbE iSCSI 4-port Cntrl 12×1.92TB SSD 4x10Gb iSCSI XCVR 23TB Storage Array



Detailed Tech Specification



Drive description : Twelve 1.92 TB Read Intensive SSDs included; Add up to twelve additional SFF HDD and/or SSD per base array

Capacity : Up to 2.71 PB with maximum capacity expansion

Storage expansion options : 2U 24-drive SFF drive enclosure and/or 2U 12-drive LFF drive enclosure (add up to 9)

Storage controller : 2x 10/25 GbE iSCSI 4-port Controller

Compatible operating systems : Windows Server®;
VMware vSphere™;
Red Hat® Linux;
SUSE™ SLES;
See HPE SPOCK for more details.

Form factor : 2U rack mount

Energy efficiency : Energy Star Compliant

Host connectivity : 10/25 GbE iSCSI

Drive form factor : SFF

Included drives : 12x HPE MSA 1.92TB SAS 12G Read Intensive SFF (2.5in) M2 3yr Wty SSD

SED Drives Supported : No

Included transceivers : HPE MSA 10Gb Short Range iSCSI SFP+ 4-pack Transceiver

Detailed product description : “Shop the HPE Smart Choice purchase program: Our most popular storage arrays, fully configured and ready to ship – now!”
HPE MSA 2070 2U small form factor all-flash storage array bundle with two 10/25 GbE iSCSI 4-port controllers, twelve 1.92 TB Read Intensive Solid State Drives, four 10 Gb iSCSI SFP+ transceivers, and two 580W redundant power supplies

Warranty : Three-year limited warranty, parts exchange next business day delivery on all base arrays and drive enclosures. MSA drives and other options carry a separate warranty.
