HPE Storage MSL3040 Tape Library 1x MSL LTO-9 Fibre Channel 20x LTO-9 45TB Data Cartridges – P84147-B25



HPE Storage MSL3040 Tape Library

HPE Storage MSL3040 Tape Library scales vertically from 40 to 640 cartridge slots to store up to 28.8 PB in a single 19-inch rack by simply adding additional modules to boost capacity without the need to invest in a whole new library.

---



Overview



Features



Highly Scalable for Greater Flexibility

• HPE Storage MSL3040 Tape Library scales vertically from 40 to 640 cartridge slots to store up to 28.8 PB in a single 19-inch rack by simply adding additional modules to boost capacity without the need to invest in a whole new library.
• Reduce cost and helps maximize ROI with better utilization of rack space—600 TB per 1U.
• Supports up to 48 half-height LTO-9, LTO-8, or LTO-7 SAS or FC Ultrium drives for exceptional performance. Drives and expansion units install easily and configure quickly without disruption.



Cost Effective Tape Storage Solution

• HPE Storage MSL3040 Tape Library offers 13 cartridge slots or 600 TB (using LTO-9 tapes and 2.5:1 compression) of capacity per 1U of rack space, scaling from 40 to 640 slots with a single expandable library; there is no need to replace it as your requirements grow.
• For investment protection, you can reuse existing LTO-9, LTO-8, or LTO-7 drives or upgrade to new drives. There are no additional license fees for installing new drives in an existing library.
• Partitioning allows each partitioned library to be presented to the host as an independent library, separate from other partitions in the library.



Enterprise-class Manageability and Reliability

• HPE Storage Tape Library Management Software manages, configures, and monitors tape libraries from any remote location through a single browser-based interface.
• HPE Storage MSL3040 Tape Library reduces human intervention and error by freeing up your resources with automated, consolidated, and simplified data protection and archive capabilities, adding more to your bottom line.
• HPE Storage Tape Library Management Software – TapeAssure Advanced provides predictive, analytical reporting of health and performance information for all drives and cartridges. It can also be used to track consumption metrics, enabling IT admins to make timely investments.
• HPE Storage Tape Library Management Software – Data Verification proactively validates and non-disruptively scans the quality of data stored on LTO tape cartridges, helping ensure the successful retrieval of data.
• Easily manage your media both in or out of the library with a standard barcode reader and removable magazines.



Reduce Risk with Advanced Security Features and Reliability

• HPE Storage MSL3040 Tape Library provides complementary layers of defense and improves security by isolating, protecting, and segregating critical data from unauthorized access and potential threats.
• Reduce the threat of cyberattack with the MSL encryption kit, a fully self-contained encryption system which can be deployed without the need for an extra server or appliance, additional software or the complexity of a full KMIP solution.
• HPE StoreEver MSL3040 Secure Manager LTU provides an additional level of security that lets you control access to the tape library by authorizing specific servers. It increases reliability by blocking disruptive traffic from unauthorized hosts to the library.
• High availability path failover uses host drivers in conjunction with library and drive firmware to manage multiple paths across multiple SANs. It presents a single drive or robot path to applications and automatically transfers commands to an alternate path if the original one is lost.



Published on lastbestprice.com

---



Short Tech Specification

HPE Storage MSL3040 Tape Library 1x MSL LTO-9 Fibre Channel 20x LTO-9 45TB Data Cartridges                        ​



Detailed Tech Specification

Drive type : LTO-9 Ultrium FC 45000

Capacity : 45 TB compressed 2.5:1 maximum

Transfer rate : 300 MB/s

Number of cartridge slots : 40 slots per module

Maximum drives per enclosure : 3 drives per module

Servers supported : See HPE Storage Single Point of Connectivity Knowledge at https://h20272.www2.hpe.com/SPOCK/

Host interface : 8 GB/s Fibre Channel
6 GB/s SAS (LTO-7, LTO-8)
12 GB/s SAS (LTO-9)

Encryption capability : AES 256-bit

Form factor : 3U per module to a maximum of 48U

Warranty : Hewlett Packard Enterprise provides a 1-year, next business day on-site, part exchange, limited warranty for the MSL3040 Tape Library and its components including drives, plus 9×5 phone support for the duration of the warranty.

Weight : The weight of each library varies based on the type and number of LTO tape drives and LTO media contained in the configuration (The weight of each library varies based on the type and number of LTO tape drives and LTO media contained in the configuration)

Dimensions : 13.3 x 48.2 x 87.3 cm (HxWxD) (5.24 x 18.98 x 34.27 in (HxWxD))
