Emerson Liebert Dual Conversion Online UPS – 10 kVA/9 kW Tower – GXT3-10000T230
For The Immediate delivery requirement contact sales team. Usually Ship in 2-3 days Back to Back 4-5 Weeks, images are for illustration purposes only.
Call for Price
Emerson Liebert Dual Conversion Online UPS – 10 kVA/9 kW Tower – GXT3-10000T230
Overview
Vertiv
Liebert GXT3 UPS meets the need for higher power capacities in small spaces. This true on-line double conversion UPS system is available in two different 10kVA versions, and features integrated maintenance bypass, as well as optional extended battery runtime.
It is available in both transformer-less and transformer-in versions. The transformer less version can work in either 1×1 or 3×1 configuration, which makes it very flexible. The isolated version is fitted with an output Isolation transformer which allows using it at 110, 120 phase to neutral or 208, 220 phase to phase voltages, for dual input with phases shifted by 180 degrees.
MAIN FEATURES |
|
|---|---|
| Plug/Connector Type | Hardwired |
| Receptacles | Hardwired |
| Load Capacity | 10 kVA/9 kW |
| Input Voltage |
|
| Output Voltage |
|
| Backup/Run Time (Full Load) | 3 Minute |
| Height | 800 mm |
| Width | 300 mm |
| Depth | 675 mm |
| Form Factor | Tower |
| Weight (Approximate) | 105 kg |
Detailed Tech Specification
GENERAL INFORMATION |
|
|---|---|
|
Manufacturer
|
Vertiv
|
|
Manufacturer Part Number
|
GXT3-10000T230
|
|
Manufacturer Website Address
|
|
|
Brand Name
|
Liebert
|
|
Product Series
|
GXT3
|
|
Product Model
|
GXT3-10000T230
|
|
Product Name
|
GXT3-10000T230 10kVA Tower UPS
|
|
Product Type
|
Dual Conversion Online UPS
|
TECHNICAL INFORMATION |
|
|
Plug/Connector Type
|
Hardwired
|
|
Receptacles
|
Hardwired
|
|
Bypass Switch
|
|
|
Emergency Power OFF
|
Yes
|
|
Phase
|
Single Phase
|
|
Application/Usage
|
|
POWER DESCRIPTION |
|
|
Load Capacity
|
10 kVA/9 kW
|
|
Input Voltage
|
|
|
Output Voltage
|
|
|
Waveform Type
|
Pure Sine Wave
|
MANAGEMENT |
|
|
Network Management
|
SNMP Manageable
|
INTERFACES/PORTS |
|
|
USB
|
Yes
|
BATTERY INFORMATION |
|
|
Battery Chemistry
|
Sealed Lead Acid (SLA)
|
|
Backup/Run Time (Full Load)
|
3 Minute
|
|
Backup/Run Time (Half Load)
|
11 Minute
|
PHYSICAL CHARACTERISTICS |
|
|
Height
|
800 mm
|
|
Width
|
300 mm
|
|
Depth
|
675 mm
|
|
Form Factor
|
Tower
|
|
Weight (Approximate)
|
105 kg
|
